| Catalog No. |
Type | Material | Teeth | Outer Dia |
Flange Dia |
Hub Dia |
Tooth width |
Total length |
Bore Dia |
n ° flange |
Mass per pc |
| de | Df | Dm | F | L | d | (q≈) | |||||
| mm | mm | mm | mm | mm | mm | ° | kg/pc | ||||
| 66 T 10 18 | 2F | Al | 18 | 55.45 | 60 | 40 | 56 | 66 | 10 | 214 | 0.4 |
| 66 T 10 19 | 2F | Al | 19 | 58.65 | 66 | 44 | 56 | 66 | 10 | 216 | 0.5 |
| 66 T 10 20 | 2F | Al | 20 | 61.80 | 66 | 46 | 56 | 66 | 12 | 216 | 0.5 |
| 66 T 10 22 | 2F | Al | 22 | 68.20 | 75 | 52 | 56 | 66 | 12 | 218 | 0.6 |
| 66 T 10 24 | 2F | Al | 24 | 74.55 | 83 | 58 | 56 | 66 | 12 | 219 | 0.7 |
| 66 T 10 25 | 2F | Al | 25 | 77.75 | 83 | 60 | 56 | 66 | 12 | 219 | 0.8 |
| 66 T 10 26 | 2F | Al | 26 | 80.90 | 87 | 60 | 56 | 66 | 12 | 220 | 0.8 |
| 66 T 10 27 | 2F | Al | 27 | 84.10 | 91 | 60 | 56 | 66 | 12 | 221 | 1.0 |
| 66 T 10 28 | 2F | Al | 28 | 87.25 | 93 | 60 | 56 | 66 | 12 | 222 | 1.0 |
| 66 T 10 30 | 2F | Al | 30 | 93.65 | 97 | 60 | 56 | 66 | 12 | 223 | 1.2 |
| 66 T 10 32 | 2F | Al | 32 | 100.00 | 106 | 65 | 56 | 66 | 12 | 224 | 1.3 |
| 66 T 10 36 | 2F | Al | 36 | 112.75 | 119 | 70 | 56 | 66 | 16 | 225 | 1.6 |
| 66 T 10 40 | 2F | Al | 40 | 125.45 | 131 | 80 | 56 | 66 | 16 | 226 | 2.0 |
| 66 T 10 44 | 2 | Al | 44 | 138.20 | 88 | 56 | 66 | 16 | 2.4 | ||
| 66 T 10 48 | 2 | Al | 48 | 150.95 | 95 | 56 | 66 | 16 | 2.8 | ||
| 66 T 10 60 | 2 | Al | 60 | 189.10 | 110 | 56 | 66 | 16 | 4.4 |
