| Sprocket No. | Do Ø mm |
Da Ø mm |
Z (T) | Dn Ø mm |
Ln mm |
d Ø mm |
| 6TS32 | 58.42 | 67.50 | 6 | 40 | 40 | 15 |
| 7TS32 | 67.32 | 76.40 | 7 | 50 | 40 | 15 |
| 8TS32 | 76.29 | 85.30 | 8 | 55 | 40 | 15 |
| 9TS32 | 85.40 | 94.50 | 9 | 60 | 40 | 15 |
| 10TS32 | 94.52 | 103.70 | 10 | 70 | 40 | 15 |
| 11TS32 | 103.67 | 112.80 | 11 | 70 | 40 | 15 |
| 12TS32 | 112.85 | 122.00 | 12 | 70 | 40 | 15 |
| 13TS32 | 122.05 | 131.20 | 13 | 70 | 40 | 15 |
| 14TS32 | 131.26 | 140.40 | 14 | 70 | 40 | 15 |
| 15TS32 | 140.49 | 149.60 | 15 | 75 | 45 | 15 |
| 16TS32 | 149.72 | 158.90 | 16 | 75 | 45 | 15 |
| 17TS32 | 158.96 | 168.10 | 17 | 75 | 45 | 15 |
| 18TS32 | 168.21 | 177.40 | 18 | 80 | 45 | 15 |
| 20TS32 | 186.71 | 195.80 | 20 | 85 | 50 | 15 |
| 21TS32 | 195.96 | 205.00 | 21 | 85 | 50 | 20 |
| 27TS32 | 251.60 | 260.70 | 27 | 90 | 50 | 20 |
| 30TS32 | 279.44 | 288.60 | 30 | 90 | 50 | 20 |
| 34TS32 | 316.57 | 325.70 | 34 | 90 | 50 | 20 |
| 38TS32 | 353.70 | 362.80 | 38 | 100 | 50 | 20 |
