| Type | Grooves | P | O | Type | Bush | Max Bore | E | F | J | K | L | M | N |
| SPA 90-04 | 4 | 90 | 95.5 | 3 | 1615 | 42 | - | 65 | 64 | 13.5 | 38 | 13.5 | - |
| SPA 95-04 | 4 | 95 | 100.5 | 3 | 1615 | 42 | - | 65 | 64 | 13.5 | 38 | 13.5 | - |
| SPA 100-04 | 4 | 100 | 105.5 | 2 | 1615 | 42 | - | 65 | 70 | - | 38 | 27 | - |
| SPA 106-04 | 4 | 106 | 111.5 | 8 | 2012 | 50 | - | 65 | 76 | 33 | 32 | - | - |
| SPA 112-04 | 4 | 112 | 117.5 | 8 | 2012 | 50 | - | 65 | 80 | 33 | 32 | - | - |
| SPA 118-04 | 4 | 118 | 123.5 | 2 | 2012 | 50 | - | 65 | 86 | - | 32 | 33 | - |
| SPA 125-04 | 4 | 125 | 130.5 | 2 | 2012 | 50 | - | 65 | 92 | - | 32 | 33 | - |
| SPA 132-04 | 4 | 132 | 137.5 | 2 | 2517 | 60 | - | 65 | 98 | - | 45 | 20 | - |
| SPA 140-04 | 4 | 140 | 145.5 | 2 | 2517 | 60 | - | 65 | 106 | - | 45 | 20 | - |
| SPA 150-04 | 4 | 150 | 155.5 | 2 | 2517 | 60 | - | 65 | 116 | - | 45 | 20 | - |
| SPA 160-04 | 4 | 160 | 165.5 | 2 | 2517 | 60 | - | 65 | 126 | - | 45 | 20 | - |
| SPA 170-04 | 4 | 170 | 175.5 | 2 | 2517 | 60 | - | 65 | 138 | - | 45 | 20 | - |
| SPA 180-04 | 4 | 180 | 185.5 | 2 | 2517 | 60 | - | 65 | 146 | - | 45 | 20 | - |
| SPA 190-04 | 4 | 190 | 195.5 | 6 | 2517 | 60 | - | 65 | 158 | - | 45 | 20 | - |
| SPA 200-04 | 4 | 200 | 205.5 | 2 | 3020 | 75 | - | 65 | 165 | - | 51 | 14 | - |
| SPA 212-04 | 4 | 212 | 217.5 | 2 | 3020 | 75 | - | 65 | 177 | - | 51 | 14 | - |
| SPA 224-04 | 4 | 224 | 229.5 | 6 | 3020 | 75 | - | 65 | 189 | - | 51 | 14 | - |
| SPA 250-04 | 4 | 250 | 255.5 | 6 | 3020 | 75 | 10 | 65 | 215 | 7 | 51 | 7 | 145 |
| SPA 280-04 | 4 | 280 | 285.5 | 6 | 3020 | 75 | 10 | 65 | 245 | 7 | 51 | 7 | 145 |
| SPA 315-04 | 4 | 315 | 320.5 | 6 | 3020 | 75 | 10 | 65 | 280 | 7 | 51 | 7 | 145 |
| SPA 355-04 | 4 | 355 | 360.5 | 5 | 3020 | 75 | - | 65 | 320 | 7 | 51 | 7 | 145 |
| SPA 400-04 | 4 | 400 | 405.5 | 5 | 3020 | 75 | - | 65 | 365 | 7 | 51 | 7 | 145 |
| SPA 450-04 | 4 | 450 | 455.5 | 5 | 3020 | 75 | - | 65 | 415 | 7 | 51 | 7 | 145 |
| SPA 500-04 | 4 | 500 | 505.5 | 5 | 3020 | 75 | - | 65 | 465 | 7 | 51 | 7 | 145 |
| SPA 560-04 | 4 | 560 | 565.5 | 4 | 3535 | 90 | - | 65 | 525 | 12 | 89 | 12 | 170 |
| SPA 630-04 | 4 | 630 | 635.5 | 4 | 3535 | 90 | - | 65 | 595 | 12 | 89 | 12 | 170 |
| SPA 800-04 | 4 | 800 | 805.5 | 4 | 3535 | 90 | - | 65 | 765 | 12 | 89 | 12 | 170 |
| SPA 1000-04 | 4 | 1000 | 1005.5 | 4 | 4040 | 90 | - | 65 | 965 | 18.5 | 102 | 18.5 | 200 |
