| Type | Grooves | P | O | Type | Bush | Max Bore | E | F | J | K | L | M | N |
| SPA 71-03 | 3 | 71 | 76.5 | 8 | 1108 | 28 | - | 50 | 40 | 28 | 22 | - | - |
| SPA 75-03 | 3 | 75 | 80.5 | 8 | 1108 | 32 | - | 50 | 44 | 25 | 25 | - | - |
| SPA 80-03 | 3 | 80 | 85.5 | 8 | 1210 | 32 | - | 50 | 47 | 25 | 25 | - | - |
| SPA 85-03 | 3 | 85 | 90.5 | 8 | 1210 | 32 | - | 50 | 50 | 25 | 25 | - | - |
| SPA 90-03 | 3 | 90 | 95.5 | 8 | 1610 | 42 | - | 50 | 60 | 25 | 25 | - | - |
| SPA 95-03 | 3 | 95 | 100.5 | 8 | 1610 | 42 | - | 50 | 64 | 25 | 25 | - | - |
| SPA 100-03 | 3 | 100 | 105.5 | 2 | 1610 | 42 | - | 50 | 70 | - | 25 | 25 | - |
| SPA 106-03 | 3 | 106 | 111.5 | 2 | 1610 | 42 | - | 50 | 76 | - | 25 | 25 | - |
| SPA 112-03 | 3 | 112 | 117.5 | 8 | 2012 | 50 | - | 50 | 83 | 18 | 32 | - | - |
| SPA 118-03 | 3 | 118 | 123.5 | 2 | 2012 | 50 | - | 50 | 86 | - | 32 | 18 | - |
| SPA 125-03 | 3 | 125 | 130.5 | 2 | 2012 | 50 | - | 50 | 92 | - | 32 | 18 | - |
| SPA 132-03 | 3 | 132 | 137.5 | 2 | 2012 | 50 | - | 50 | 98 | - | 32 | 18 | - |
| SPA 140-03 | 3 | 140 | 145.5 | 8 | 2517 | 60 | - | 50 | 106 | 5 | 45 | - | - |
| SPA 150-03 | 3 | 150 | 155.5 | 8 | 2517 | 60 | - | 50 | 116 | 5 | 45 | - | - |
| SPA 160-03 | 3 | 160 | 165.5 | 8 | 2517 | 60 | - | 50 | 126 | 5 | 45 | - | - |
| SPA 170-03 | 3 | 170 | 175.5 | 8 | 2517 | 60 | - | 50 | 138 | 5 | 45 | - | - |
| SPA 180-03 | 3 | 180 | 185.5 | 8 | 2517 | 60 | - | 50 | 146 | 5 | 45 | - | - |
| SPA 190-03 | 3 | 190 | 195.5 | 6 | 2517 | 60 | - | 50 | 158 | 5 | 45 | - | - |
| SPA 200-03 | 3 | 200 | 205.5 | 6 | 2517 | 60 | 20 | 50 | 165 | 2.5 | 45 | 2.5 | 120 |
| SPA 212-03 | 3 | 212 | 217.5 | 6 | 2517 | 60 | 20 | 50 | 177 | 2.5 | 45 | 2.5 | 120 |
| SPA 224-03 | 3 | 224 | 229.5 | 6 | 2517 | 60 | 20 | 50 | 189 | 2.5 | 45 | 2.5 | 120 |
| SPA 250-03 | 3 | 250 | 255.5 | 5 | 2517 | 60 | 20 | 50 | 215 | 2.5 | 45 | 2.5 | 120 |
| SPA 280-03 | 3 | 280 | 285.5 | 5 | 2517 | 60 | 20 | 50 | 245 | 2.5 | 45 | 2.5 | 120 |
| SPA 315-03 | 3 | 315 | 320.5 | 4 | 3020 | 75 | 25 | 50 | 280 | 0.5 | 51 | 0.5 | 145 |
| SPA 355-03 | 3 | 355 | 360.5 | 4 | 3020 | 75 | - | 50 | 320 | 0.5 | 51 | 0.5 | 145 |
| SPA 400-03 | 3 | 400 | 405.5 | 4 | 3020 | 75 | - | 50 | 365 | 0.5 | 51 | 0.5 | 145 |
| SPA 450-03 | 3 | 450 | 455.5 | 4 | 3020 | 75 | - | 50 | 415 | 0.5 | 51 | 0.5 | 145 |
| SPA 500-03 | 3 | 500 | 505.5 | 4 | 3020 | 75 | - | 50 | 465 | 0.5 | 51 | 0.5 | 145 |
| SPA 560-03 | 3 | 560 | 565.5 | 4 | 3020 | 75 | - | 50 | 525 | 0.5 | 51 | 0.5 | 145 |
| SPA 630-03 | 3 | 630 | 635.5 | 4 | 3020 | 75 | - | 50 | 595 | 0.5 | 51 | 0.5 | 145 |
| SPA 800-03 | 3 | 800 | 805.5 | 4 | 3535 | 90 | - | 50 | 765 | 19.5 | 89 | 19.5 | 170 |
| SPA 1000-03 | 3 | 1000 | 1005.5 | 4 | 3535 | 90 | - | 50 | 965 | 19.5 | 89 | 19.5 | 170 |
