| Type | Grooves | P | O | Type | Bush | Max Bore | E | F | J | K | L | M | N |
| SPA 63-01 | 1 | 63 | 68.5 | 9 | 1108 | 28 | - | 40 | 30 | 18 | 22 | - | - |
| SPA 67-01 | 1 | 67 | 72.5 | 1 | 1108 | 28 | - | 20 | 38 | - | 22 | 2 | 62 |
| SPA 71-01 | 1 | 71 | 76.5 | 1 | 1108 | 28 | - | 20 | - | - | 22 | 2 | 62 |
| SPA 75-01 | 1 | 75 | 80.5 | 1 | 1108 | 28 | - | 20 | - | - | 22 | 2 | 62 |
| SPA 80-01 | 1 | 80 | 85.5 | 1 | 1210 | 32 | - | 20 | - | - | 25 | 5 | 75 |
| SPA 85-01 | 1 | 85 | 90.5 | 1 | 1210 | 32 | - | 20 | - | - | 25 | 5 | 75 |
| SPA 90-01 | 1 | 90 | 95.5 | 1 | 1210 | 32 | - | 20 | - | - | 25 | 5 | 75 |
| SPA 95-01 | 1 | 95 | 100.5 | 1 | 1210 | 32 | - | 20 | - | - | 25 | 5 | 75 |
| SPA 100-01 | 1 | 100 | 105.5 | 1 | 1610 | 42 | - | 20 | - | - | 25 | 5 | 80 |
| SPA 106-01 | 1 | 106 | 111.5 | 1 | 1610 | 42 | - | 20 | - | - | 25 | 5 | 80 |
| SPA 112-01 | 1 | 112 | 117.5 | 1 | 1610 | 42 | - | 20 | - | - | 25 | 5 | 80 |
| SPA 118-01 | 1 | 118 | 123.5 | 1 | 1610 | 42 | - | 20 | - | - | 25 | 5 | 80 |
| SPA 125-01 | 1 | 125 | 130.5 | 1 | 1610 | 42 | - | 20 | - | - | 25 | 5 | 80 |
| SPA 132-01 | 1 | 132 | 137.5 | 1 | 1610 | 42 | - | 20 | - | - | 25 | 5 | 80 |
| SPA 140-01 | 1 | 140 | 145.5 | 7 | 1610 | 42 | - | 20 | 110 | - | 25 | 5 | 80 |
| SPA 150-01 | 1 | 150 | 155.5 | 7 | 1610 | 42 | - | 20 | 118 | - | 25 | 5 | 80 |
| SPA 160-01 | 1 | 160 | 165.5 | 7 | 1610 | 42 | - | 20 | 128 | - | 25 | 5 | 80 |
| SPA 170-01 | 1 | 170 | 175.5 | 7 | 1610 | 42 | - | 20 | 138 | - | 25 | 5 | 80 |
| SPA 180-01 | 1 | 180 | 185.5 | 7 | 1610 | 42 | - | 20 | 148 | - | 25 | 5 | 80 |
| SPA 190-01 | 1 | 190 | 195.5 | 7 | 1610 | 42 | - | 20 | 158 | - | 25 | 5 | 80 |
| SPA 200-01 | 1 | 200 | 205.5 | 7 | 2012 | 50 | 10 | 20 | 165 | - | 32 | 12 | 100 |
| SPA 212-01 | 1 | 212 | 217.5 | 7 | 2012 | 50 | 10 | 20 | 177 | - | 32 | 12 | 100 |
| SPA 224-01 | 1 | 224 | 229.5 | 4 | 2012 | 50 | 10 | 20 | 189 | - | 32 | 12 | 100 |
| SPA 250-01 | 1 | 250 | 255.5 | 4 | 2012 | 50 | 10 | 20 | 215 | - | 32 | 12 | 100 |
| SPA 280-01 | 1 | 280 | 285.5 | 4 | 2012 | 50 | 10 | 20 | 245 | - | 32 | 12 | 100 |
| SPA 315-01 | 1 | 315 | 320.5 | 4 | 2012 | 50 | - | 20 | 280 | - | 32 | 12 | 100 |
| SPA 355-01 | 1 | 355 | 360.5 | 4 | 2012 | 50 | - | 20 | 320 | - | 32 | 12 | 100 |
| SPA 400-01 | 1 | 400 | 405.5 | 4 | 2012 | 50 | - | 20 | 365 | - | 32 | 12 | 100 |
| SPA 450-01 | 1 | 450 | 455.5 | 4 | 2012 | 50 | - | 20 | 415 | - | 32 | 12 | 100 |
| SPA 500-01 | 1 | 500 | 505.5 | 4 | 2517 | 60 | - | 20 | 465 | - | 45 | 25 | 120 |
| SPA 630-01 | 1 | 630 | 635.5 | 4 | 2517 | 60 | - | 20 | 595 | - | 45 | 25 | 120 |
