| Chain No. | Pitch | Lacing | Plates depth |
Plate thickness |
Pin diameter |
Width over riveted pins | Hole diameter of inner plates | Ultimate tensile strength | Mass per meter |
| ISO DIN | P | h2 max | T max | d2 max | L max | d1 min | Fu min | q≈ | |
| mm | mm | mm | mm | mm | mm | kN | kg/m | ||
| LL0822 | 12.7 | 2X2 | 10.92 | 1.55 | 4.45 | 8.5 | 4.46 | 18.0 | 0.40 |
| LL0844 | 4X4 | 14.6 | 36.0 | 0.80 | |||||
| LL0866 | 6X6 | 20.7 | 54.0 | 1.20 | |||||
| LL1022 | 15.875 | 2X2 | 13.72 | 1.65 | 5.08 | 9.3 | 5.09 | 22.0 | 0.50 |
| LL1044 | 4X4 | 16.1 | 44.0 | 1.00 | |||||
| LL1066 | 6X6 | 22.9 | 66.0 | 1.50 | |||||
| LL1222 | 19.05 | 2X2 | 16.13 | 1.9 | 5.72 | 10.7 | 5.73 | 29.0 | 0.70 |
| LL1244 | 4X4 | 18.5 | 58.0 | 1.30 | |||||
| LL1266 | 6X6 | 26.3 | 87.0 | 2.00 | |||||
| LL1622 | 25.4 | 2X2 | 21.08 | 3.2 | 8.28 | 17.2 | 8.3 | 60.0 | 1.50 |
| LL1644 | 4X4 | 30.2 | 120.0 | 3.00 | |||||
| LL1666 | 6X6 | 43.2 | 180.0 | 4.40 | |||||
| LL2022 | 31.75 | 2X2 | 26.42 | 3.7 | 10.19 | 20.1 | 10.21 | 95.0 | 2.30 |
| LL2044 | 4X4 | 35.1 | 190.0 | 4.40 | |||||
| LL2066 | 6X6 | 50.1 | 285.0 | 6.60 | |||||
| LL2422 | 38.1 | 2X2 | 33.4 | 5.2 | 14.63 | 28.4 | 14.65 | 170.0 | 4.40 |
| LL2444 | 4X4 | 49.4 | 340.0 | 8.50 | |||||
| LL2466 | 6X6 | 70.4 | 510.0 | 12.50 | |||||
| LL2822 | 44.45 | 2X2 | 37.08 | 6.45 | 15.9 | 34.0 | 15.92 | 200.0 | 5.40 |
| LL2844 | 4X4 | 60.0 | 400.0 | 10.50 | |||||
| LL2866 | 6X6 | 86.0 | 600.0 | 15.50 | |||||
| LL3222 | 50.8 | 2X2 | 42.29 | 6.45 | 17.81 | 35.0 | 17.83 | 260.0 | 6.20 |
| LL3244 | 4X4 | 61.0 | 520.0 | 12.10 | |||||
| LL3266 | 6X6 | 87.0 | 780.0 | 18.00 | |||||
| LL4022 | 63.5 | 2X2 | 52.96 | 8.25 | 22.89 | 44.7 | 22.91 | 360.0 | 10.30 |
| LL4044 | 4X4 | 77.9 | 720.0 | 20.00 | |||||
| LL4066 | 6X6 | 111.1 | 1080.0 | 29.50 | |||||
| LL4822 | 76.2 | 2X2 | 63.88 | 10.3 | 29.24 | 56.1 | 29.26 | 560.0 | 18.50 |
| LL4844 | 4X4 | 97.4 | 1120.0 | 35.70 | |||||
| LL4866 | 6X6 | 138.9 | 1168.0 | 53.00 |
