| Chain No. | Pitch | Lacing | plates depth |
Plate thickness |
Pin diameter |
width over riveted pins | Hole diameter of inner plates | Ultimate tensile strength | Mass per meter | |
| GB ISO DIN | ASME | P | h2 max | T max | d2 max | L max | d1 min | Fu min | q≈ | |
| mm | mm | mm | mm | mm | mm | kN | kg/m | |||
| LH0822 | BL422 | 12.70 | 2×2 | 12.07 | 2.08 | 5.09 | 11.1 | 5.11 | 22.2 | 0.64 |
| LH0823 | BL423 | 2×3 | 13.2 | 22.4 | 0.80 | |||||
| LH0834 | BL434 | 3×4 | 17.4 | 33.4 | 1.12 | |||||
| LH0844 | BL444 | 4×4 | 19.6 | 44.5 | 1.28 | |||||
| LH0846 | BL446 | 4×6 | 23.8 | 44.5 | 1.60 | |||||
| LH0866 | BL466 | 6×6 | 28.0 | 66.7 | 1.92 | |||||
| LH0888 | BL488 | 8×8 | 36.4 | 88.8 | 2.56 | |||||
| LH1022 | BL522 | 15.875 | 2×2 | 15.09 | 2.48 | 5.96 | 12.9 | 5.98 | 33.4 | 0.88 |
| LH1023 | BL523 | 2×3 | 15.4 | 33.4 | 1.10 | |||||
| LH1034 | BL534 | 3×4 | 20.4 | 48.9 | 1.50 | |||||
| LH1044 | BL544 | 4×4 | 22.8 | 66.7 | 1.80 | |||||
| LH1046 | BL546 | 4×6 | 27.7 | 66.7 | 2.20 | |||||
| LH1066 | BL566 | 6×6 | 32.7 | 100.1 | 2.65 | |||||
| LH1088 | BL588 | 8×8 | 42.6 | 133.6 | 3.50 | |||||
| LH1222 | BL622 | 19.05 | 2×2 | 18.11 | 3.30 | 7.94 | 17.4 | 7.96 | 48.9 | 1.45 |
| LH1223 | BL623 | 2×3 | 20.8 | 48.9 | 1.80 | |||||
| LH1234 | BL634 | 3×4 | 27.5 | 75.6 | 2.50 | |||||
| LH1244 | BL644 | 4×4 | 30.8 | 97.9 | 2.90 | |||||
| LH1246 | BL646 | 4×6 | 37.5 | 97.9 | 3.60 | |||||
| LH1266 | BL666 | 6×6 | 44.2 | 146.8 | 4.30 | |||||
| LH1288 | BL688 | 8×8 | 57.6 | 195.6 | 5.80 | |||||
| LH1622 | BL822 | 25.40 | 2×2 | 24.13 | 4.09 | 9.54 | 21.4 | 9.56 | 84.5 | 2.20 |
| LH1623 | BL823 | 2×3 | 25.5 | 84.5 | 2.70 | |||||
| LH1634 | BL834 | 3×4 | 33.8 | 129.0 | 3.80 | |||||
| LH1644 | BL844 | 4×4 | 37.9 | 169.0 | 4.30 | |||||
| LH1646 | BL846 | 4×6 | 46.2 | 169.0 | 5.40 | |||||
| LH1666 | BL866 | 6×6 | 54.5 | 253.6 | 6.50 | |||||
| LH1688 | BL888 | 8×8 | 71.0 | 338.0 | 8.60 | |||||
| LH2022 | BL1022 | 31.75 | 2×2 | 30.18 | 4.90 | 11.11 | 25.4 | 11.14 | 115.60 | 3.40 |
| LH1023 | BL1023 | 2×3 | 30.4 | 115.60 | 4.30 | |||||
| LH2034 | BL1034 | 3×4 | 40.3 | 182.40 | 6.00 | |||||
| LH2044 | BL1044 | 4×4 | 45.2 | 231.30 | 6.90 | |||||
| LH2046 | BL1046 | 4×6 | 55.1 | 231.30 | 8.60 | |||||
| LH2066 | BL1066 | 6×6 | 65.0 | 347.00 | 10.30 | |||||
| LH2088 | BL1088 | 8×8 | 84.8 | 462.40 | 13.80 | |||||
| LH2422 | BL1222 | 38.10 | 2×2 | 36.20 | 5.77 | 12.71 | 29.7 | 12.74 | 151.20 | 4.60 |
| LH2423 | BL1223 | 2×3 | 35.5 | 151.20 | 5.80 | |||||
| LH2434 | BL1234 | 3×4 | 47.1 | 244.60 | 8.10 | |||||
| LH2444 | BL1244 | 4×4 | 52.9 | 302.50 | 9.30 | |||||
| LH2446 | BL1246 | 4×6 | 64.6 | 302.50 | 11.60 | |||||
| LH2466 | BL1266 | 6×6 | 76.2 | 453.70 | 13.90 | |||||
| LH2488 | BL1288 | 8×8 | 99.4 | 604.80 | 18.60 | |||||
| LH2822 | BL1422 | 44.45 | 2×2 | 42.24 | 6.60 | 14.29 | 33.6 | 14.31 | 191.30 | 6.10 |
| LH2823 | BL1423 | 2×3 | 40.2 | 191.30 | 7.60 | |||||
| LH2834 | BL1434 | 3×4 | 53.4 | 315.80 | 10.60 | |||||
| LH2844 | BL1444 | 4×4 | 60.0 | 382.60 | 12.20 | |||||
| LH2846 | BL1446 | 4×6 | 73.2 | 382.60 | 15.20 | |||||
| LH2866 | BL1466 | 6×6 | 86.4 | 578.30 | 18.20 | |||||
| LH2888 | BL1488 | 8×8 | 112.3 | 765.20 | 24.30 | |||||
| LH3222 | BL1622 | 50.80 | 2×2 | 48.26 | 7.52 | 17.46 | 40.0 | 17.49 | 289.10 | 8.00 |
| LH3223 | BL1623 | 2×3 | 46.6 | 289.10 | 10.00 | |||||
| LH3234 | BL1634 | 3×4 | 61.8 | 440.40 | 14.00 | |||||
| LH3244 | BL1644 | 4×4 | 69.3 | 578.30 | 16.00 | |||||
| LH3246 | BL1646 | 4×6 | 84.5 | 578.30 | 20.00 | |||||
| LH3266 | BL1666 | 6×6 | 100.0 | 857.40 | 24.00 | |||||
| LH3288 | BL1688 | 8×8 | 129.8 | 1156.40 | 32.00 | |||||
| LH4022 | BL2022 | 63.50 | 2×2 | 60.33 | 9.91 | 23.81 | 51.8 | 23.84 | 433.70 | 15.80 |
| LH4023 | BL2023 | 2×3 | 61.7 | 433.70 | 19.80 | |||||
| LH4034 | BL2034 | 3×4 | 81.7 | 649.40 | 27.70 | |||||
| LH4044 | BL2044 | 4×4 | 91.6 | 867.40 | 31.60 | |||||
| LH4046 | BL2046 | 4×6 | 111.5 | 867.40 | 39.50 | |||||
| LH4066 | BL2066 | 6×6 | 131.4 | 1301.10 | 47.40 | |||||
| LH4088 | BL2088 | 8×8 | 171.2 | 1734.80 | 63.20 | |||||
