| Chain No. | Pitch | Roller diameter | Width between inner plates | Pin diameter | Width over bearing pins | Width over connecting pins |
Inner plates depth | Plate thickness | Ultimate tensile strength | Mass per meter |
|
| GB ISO DIN | ANSI | P | d1 max | b1 min | d2 max | L max | Lc max | h2 max | T | min | q ≈ |
| mm | mm | mm | mm | mm | mm | mm | mm | kN(lb) | kg/m | ||
| C208A C208AL | C2040 C2042 | 25.40 25.40 |
7.95 15.88 |
7.85 7.85 |
3.98 3.98 |
17.80 17.80 |
21.70 21.70 |
12.07 12.07 |
1.52 1.52 |
13.90 13.90 |
0.50 0.84 |
| C208B C208BL | 25.40 25.40 |
8.51 15.88 |
7.75 7.75 |
4.45 4.45 |
17.00 17.00 |
20.90 20.90 |
11.81 11.81 |
1.60 1.60 |
17.80 17.80 |
0.55 0.89 |
|
| C210A C210AL | C2050 C2052 | 31.75 31.75 |
10.16 19.05 |
9.40 9.40 |
5.09 5.09 |
21.80 21.80 |
25.90 25.90 |
15.09 15.09 |
2.03 2.03 |
21.80 21.80 |
0.78 1.27 |
| C212A C212AL | C2060 C2062 | 38.10 38.10 |
11.91 22.23 |
12.57 12.57 |
5.96 5.96 |
26.90 26.90 |
31.50 31.50 |
18.10 18.10 |
2.39 2.39 |
31.30 31.30 |
1.12 1.61 |
| C212A-H C212AL-H | C2060H C2062H | 38.10 38.10 |
11.91 22.23 |
12.57 12.57 |
5.96 5.96 |
30.20 30.20 |
34.80 34.80 |
18.10 18.10 |
3.18 3.18 |
31.30 31.30 |
1.44 2.07 |
| C216A C216AL | C2080 C2082 | 50.80 50.80 |
15.88 28.58 |
15.75 15.75 |
7.94 7.94 |
33.50 33.50 |
38.90 38.90 |
24.13 24.13 |
3.18 3.18 |
55.60 55.60 |
2.08 3.12 |
| C216A-H C216AL-H | C2080H C2082H | 50.80 50.80 |
15.88 28.58 |
15.75 15.75 |
7.94 7.94 |
37.40 37.40 |
42.80 42.80 |
24.13 24.13 |
3.96 3.96 |
55.60 55.60 |
2.54 3.58 |
| C220A C220AL | C2100 C2102 | 63.50 63.50 |
19.05 39.67 |
18.90 18.90 |
9.54 9.54 |
41.10 41.10 |
47.20 47.20 |
30.17 30.17 |
3.96 3.96 |
87.00 87.00 |
3.01 4.83 |
| C220A-H C220AL-H | C2100H C2102H | 63.50 63.50 |
19.05 39.67 |
18.90 18.90 |
9.54 9.54 |
44.50 44.50 |
50.60 50.60 |
30.17 30.17 |
4.75 4.75 |
87.00 87.00 |
3.56 5.38 |
| C224A C224AL | C2120 C2122 | 76.20 76.20 |
22.23 44.45 |
25.22 25.22 |
11.11 11.11 |
50.80 50.80 |
57.40 57.40 |
36.20 36.20 |
4.75 4.75 |
125.00 125.00 |
4.66 7.66 |
| C224A-H C224AL-H | C2120H C2122H | 76.20 76.20 |
22.23 44.45 |
25.22 25.22 |
11.11 11.11 |
55.00 55.00 |
61.60 61.60 |
36.20 36.20 |
5.56 5.56 |
125.00 125.00 |
5.26 8.26 |
| C232A C232AL | C2160 C2162 | 101.60 101.60 |
28.58 57.15 |
31.55 31.55 |
14.29 14.29 |
65.50 65.50 |
73.40 73.40 |
48.26 48.26 |
6.35 6.35 |
222.40 222.40 |
8.15 13.00 |
| C232A-H C232AL-H | C2160H C2162H | 101.60 101.60 |
28.58 57.15 |
31.55 31.55 |
14.29 14.29 |
69.40 69.40 |
77.30 77.30 |
48.26 48.26 |
7.14 7.14 |
222.40 222.40 |
9.06 13.84 |
