| Chain No. | Pitch | Roller diameter | Width between inner plates | Pin diameter |
Width over bearing pins | Width over connecting pins |
plates depth | Transverse pitch | Plate thickness |
Ultimate tensile strength | Average tensile strength | Mass per meter | |
| GB ISO DIN | ANSI | p | d1 max | b1 min | d2 max | L max | Lc max | h2 max | pt | T | Fu min | Fua | q ≈ |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | kN | kN | kg/m | ||
| C08A-1 | C40 | 12.70 | 7.92 | 7.85 | 3.98 | 17.8 | 21.7 | 12.07 | - | 1.52 | 13.9 | 17.0 | 0.73 |
| C08A-2 | C40-2 | 12.70 | 7.92 | 7.85 | 3.98 | 32.3 | 36.2 | 12.07 | 14.38 | 1.52 | 27.8 | 34.0 | 1.43 |
| C08A-3 | C40-3 | 12.70 | 7.92 | 7.85 | 3.98 | 46.7 | 50.6 | 12.07 | 14.38 | 1.52 | 41.7 | 47.5 | 2.14 |
| C10A-1 | C50 | 15.875 | 10.16 | 9.40 | 5.09 | 21.8 | 25.9 | 15.09 | - | 2.03 | 21.8 | 28.0 | 1.23 |
| C10A-2 | C50-2 | 15.875 | 10.16 | 9.40 | 5.09 | 39.9 | 44.0 | 15.09 | 18.11 | 2.03 | 43.6 | 55.0 | 2.42 |
| C10A-3 | C50-3 | 15.875 | 10.16 | 9.40 | 5.09 | 57.9 | 62.0 | 15.09 | 18.11 | 2.03 | 65.4 | 74.0 | 3.60 |
| C12A-1 | C60 | 19.05 | 11.91 | 12.57 | 5.96 | 26.9 | 31.5 | 18.10 | - | 2.39 | 31.3 | 40.0 | 1.80 |
| C12A-2 | C60-2 | 19.05 | 11.91 | 12.57 | 5.96 | 49.8 | 54.4 | 18.10 | 22.78 | 2.39 | 62.6 | 80.0 | 3.55 |
| C12A-3 | C60-3 | 19.05 | 11.91 | 12.57 | 5.96 | 72.6 | 77.2 | 18.10 | 22.78 | 2.39 | 93.9 | 106.0 | 5.30 |
| C16A-1 | C80 | 25.40 | 15.88 | 15.75 | 7.94 | 33.5 | 38.9 | 24.13 | - | 3.18 | 55.6 | 66.0 | 3.09 |
| C16A-2 | C80-2 | 25.40 | 15.88 | 15.75 | 7.94 | 62.7 | 68.1 | 24.13 | 29.29 | 3.18 | 111.2 | 135.0 | 6.12 |
| C16A-3 | C80-3 | 25.40 | 15.88 | 15.75 | 7.94 | 91.9 | 97.3 | 24.13 | 29.29 | 3.18 | 166.8 | 188.5 | 9.10 |
| C20A-1 | C100 | 31.75 | 19.05 | 18.90 | 9.54 | 41.1 | 47.2 | 30.17 | - | 3.96 | 87.0 | 104.0 | 4.56 |
| C20A-2 | C100-2 | 31.75 | 19.05 | 18.90 | 9.54 | 77.0 | 83.1 | 30.17 | 35.76 | 3.96 | 174.0 | 208.0 | 9.08 |
| C20A-3 | C100-3 | 31.75 | 19.05 | 18.90 | 9.54 | 113.0 | 119.1 | 30.17 | 35.76 | 3.96 | 261.0 | 294.0 | 13.60 |
| C24A-1 | C120 | 38.10 | 22.23 | 25.22 | 11.11 | 50.8 | 57.4 | 36.20 | - | 4.75 | 125.0 | 148.0 | 6.86 |
| C24A-2 | C120-2 | 38.10 | 22.23 | 25.22 | 11.11 | 96.3 | 102.9 | 36.20 | 45.44 | 4.75 | 250.0 | 299.0 | 13.60 |
| C24A-3 | C120-3 | 38.10 | 22.23 | 25.22 | 11.11 | 141.7 | 148.3 | 36.20 | 45.44 | 4.75 | 375.0 | 415.0 | 20.43 |
| C28A-1 | C140 | 44.45 | 25.40 | 25.22 | 12.71 | 54.9 | 62.3 | 42.23 | - | 5.56 | 170.0 | 201.0 | 8.49 |
| C28A-2 | C140-2 | 44.45 | 25.40 | 25.22 | 12.71 | 103.6 | 111.0 | 42.23 | 48.87 | 5.56 | 340.0 | 406.0 | 16.86 |
| C28A-3 | C140-3 | 44.45 | 25.40 | 25.22 | 12.71 | 152.4 | 159.8 | 42.23 | 48.87 | 5.56 | 510.0 | 564.0 | 25.23 |
| C32A-1 | C160 | 50.80 | 28.58 | 31.55 | 14.29 | 65.5 | 73.4 | 48.26 | - | 6.35 | 223.0 | 265.0 | 11.50 |
| C32A-2 | C160-2 | 50.80 | 28.58 | 31.55 | 14.29 | 124.2 | 132.1 | 48.26 | 58.55 | 6.35 | 446.0 | 534.0 | 22.90 |
| C32A-3 | C160-3 | 50.80 | 28.58 | 31.55 | 14.29 | 182.9 | 190.8 | 48.26 | 58.55 | 6.35 | 669.0 | 742.0 | 34.19 |
