| Chain No. |
Pitch | Roller diameter |
Width between inner plates |
Pin diameter |
Width over bearing pins |
Width over connecting pins |
Inner plates depth |
Transverse pitch |
Plate thickness |
Ultimate tensile strength |
Average tensile strength |
Mass per meter |
| GB ISO ANSI |
p | d1 max | b1 min | d2 max | L max | Lc max | h2 max | pt | T | Fu min | Fua | q≈ |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | kN | kN | kg/m | |
| 60H | 19.05 | 11.91 | 12.57 | 5.96 | 30.2 | 34.8 | 38.1 | - | 3.18 | 31.3 | 40.6 | 1.87 |
| 60H-2 | 19.05 | 11.91 | 12.57 | 5.96 | 56.3 | 60.9 | 18.10 | 26.11 | 3.18 | 62.6 | 80.3 | 3.71 |
| 60H-3 | 19.05 | 11.91 | 12.57 | 5.96 | 82.4 | 87.0 | 18.10 | 26.11 | 3.18 | 93.9 | 108.2 | 5.54 |
| 80H | 25.40 | 15.88 | 15.75 | 7.94 | 37.4 | 42.8 | 24.13 | - | 3.96 | 55.6 | 67.8 | 3.10 |
| 80H-2 | 25.40 | 15.88 | 15.75 | 7.94 | 70.0 | 75.4 | 24.13 | 32.59 | 3.96 | 111.2 | 138.0 | 6.15 |
| 80H-3 | 25.40 | 15.88 | 15.75 | 7.94 | 102.6 | 108.0 | 24.13 | 32.59 | 3.96 | 166.8 | 193.0 | 9.42 |
| 100H | 31.75 | 19.05 | 18.90 | 9.54 | 44.5 | 50.6 | 30.17 | - | 4.75 | 87.0 | 106.8 | 4.52 |
| 100H-2 | 31.75 | 19.05 | 18.90 | 9.54 | 83.6 | 89.7 | 30.17 | 39.09 | 4.75 | 174.0 | 214.0 | 9.03 |
| 100H-3 | 31.75 | 19.05 | 18.90 | 9.54 | 122.7 | 128.8 | 30.17 | 39.09 | 4.75 | 261.0 | 299.0 | 12.96 |
| 120H | 38.10 | 22.23 | 25.22 | 11.11 | 55.0 | 61.6 | 36.20 | - | 5.56 | 125.0 | 153.0 | 6.60 |
| 120H-2 | 38.10 | 22.23 | 25.22 | 11.11 | 103.9 | 110.5 | 36.20 | 48.87 | 5.56 | 250.0 | 306.0 | 13.13 |
| 120H-3 | 38.10 | 22.23 | 25.22 | 11.11 | 152.8 | 159.4 | 36.20 | 48.87 | 5.56 | 375.0 | 422.0 | 19.64 |
| 140H | 44.45 | 25.40 | 25.22 | 12.71 | 59.0 | 66.4 | 42.23 | - | 6.35 | 170.0 | 206.0 | 8.30 |
| 140H-2 | 44.45 | 25.40 | 25.22 | 12.71 | 111.2 | 118.6 | 42.23 | 52.20 | 6.35 | 340.0 | 416.0 | 16.60 |
| 140H-3 | 44.45 | 25.40 | 25.22 | 12.71 | 163.4 | 170.8 | 42.23 | 52.20 | 6.35 | 510.0 | 568.0 | 24.90 |
| 160H | 50.80 | 28.58 | 31.55 | 14.29 | 69.4 | 77.3 | 48.26 | - | 7.14 | 223.0 | 272.0 | 11.20 |
| 160H-2 | 50.80 | 28.58 | 31.55 | 14.29 | 131.3 | 139.2 | 48.26 | 61.90 | 7.14 | 446.0 | 543.0 | 22.30 |
| 160H-3 | 50.80 | 28.58 | 31.55 | 14.29 | 193.2 | 201.1 | 48.26 | 61.90 | 7.14 | 669.0 | 748.0 | 33.50 |
| 180H | 57.15 | 35.71 | 35.48 | 17.46 | 77.3 | 86.4 | 54.30 | - | 7.92 | 281.0 | 325.0 | 14.83 |
| 180H-2 | 57.15 | 35.71 | 35.48 | 17.46 | 146.5 | 155.6 | 54.30 | 69.16 | 7.92 | 562.0 | 643.0 | 29.60 |
| 180H-3 | 57.15 | 35.71 | 35.48 | 17.46 | 215.7 | 224.7 | 54.30 | 69.16 | 7.92 | 843.0 | 890.0 | 44.40 |
| 200H | 63.50 | 39.68 | 37.85 | 19.85 | 87.1 | 97.3 | 60.33 | - | 9.52 | 347.0 | 422.0 | 19.16 |
| 200H-2 | 63.50 | 39.68 | 37.85 | 19.85 | 165.4 | 175.6 | 60.33 | 78.31 | 9.52 | 694.0 | 850.0 | 38.30 |
| 200H-3 | 63.50 | 39.68 | 37.85 | 19.85 | 243.7 | 253.9 | 60.33 | 78.31 | 9.52 | 1041.0 | 1167.0 | 57.46 |
| 240H | 76.20 | 47.63 | 47.35 | 23.81 | 111.4 | 121.9 | 72.39 | - | 12.70 | 500.0 | 591.0 | 30.40 |
| 240H-2 | 76.20 | 47.63 | 47.35 | 23.81 | 212.6 | 223.1 | 72.39 | 101.22 | 12.70 | 1000.0 | 1167.0 | 60.80 |
| 240H-3 | 76.20 | 47.63 | 47.35 | 23.81 | 313.8 | 324.3 | 72.39 | 101.22 | 12.70 | 1500.0 | 1620.0 | 91.10 |
