Plate wheels for simplex, duplex and triplex chain to: DIN 8188 - ISO/R 606 - ANSI B 29,1
Discos para cadena simple, doble y triple de rodillos segun: DIN 8188 - ISO/R 606 - ANSI B 29,1
Corone per catene semplici, doppie e triple a rulli secondo: DIN 8188 - ISO/R 606 - ANSI B 29,1
Kettenradscheiben mit einseitiger Nabe für Simplex- Duplex- Triplex-Rollenkette nach: DIN 8188 - ISO/R 606 - ANSI B 29,1
Disques avec moyeu déporté pour chaînes simples, doubles et triples à rouleaux suivant les normes: DIN 8188 - ISO/R 606 - ANSI B 29,1
| Sprocket Data |
Inch |
Metric |
| B1: |
0.168 |
4.30 |
| b1: |
0.162 |
4.11 |
| B2: |
0.561 |
14.25 |
| b1: |
0.162 |
4.10 |
| B3: |
0.960 |
24.38 |
|
| Teeth |
Outer Dia de |
Simplex |
Duplex |
Triplex |
| Inch bore |
Metric bore |
Inch bore |
Metric bore |
Inch bore |
Metric bore |
| Inch |
Metric |
D1 |
D1 |
D1 |
D1 |
D1 |
D1 |
| 8 |
1.13 |
28.70 |
3/8 |
8 |
- |
8 |
- |
8 |
| 9 |
1.26 |
32.00 |
3/8 |
8 |
- |
8 |
- |
8 |
| 10 |
1.38 |
35.05 |
3/8 |
8 |
- |
8 |
- |
10 |
| 11 |
1.50 |
38.10 |
3/8 |
8 |
- |
10 |
- |
12 |
| 12 |
1.63 |
41.40 |
1/2 |
8 |
1/2 |
10 |
- |
12 |
| 13 |
1.75 |
44.45 |
1/2 |
8 |
1/2 |
10 |
1/2 |
12 |
| 14 |
1.87 |
47.50 |
1/2 |
8 |
1/2 |
10 |
1/2 |
12 |
| 15 |
1.99 |
50.55 |
1/2 |
8 |
1/2 |
10 |
1/2 |
12 |
| 16 |
2.11 |
53.59 |
1/2 |
10 |
1/2 |
12 |
1/2 |
12 |
| 17 |
2.23 |
56.64 |
1/2 |
10 |
1/2 |
12 |
1/2 |
12 |
| 18 |
2.35 |
59.69 |
1/2 |
10 |
1/2 |
12 |
1/2 |
12 |
| 19 |
2.47 |
62.74 |
1/2 |
10 |
1/2 |
12 |
1/2 |
12 |
| 20 |
2.59 |
65.79 |
1/2 |
10 |
3/4 |
12 |
3/4 |
12 |
| 21 |
2.71 |
68.83 |
1/2 |
12 |
3/4 |
16 |
3/4 |
16 |
| 22 |
2.83 |
71.88 |
1/2 |
12 |
3/4 |
16 |
3/4 |
16 |
| 23 |
2.95 |
74.93 |
1/2 |
12 |
3/4 |
16 |
3/4 |
16 |
| 24 |
3.07 |
77.98 |
1/2 |
12 |
3/4 |
16 |
3/4 |
16 |
| 25 |
3.19 |
81.03 |
1/2 |
12 |
3/4 |
16 |
3/4 |
16 |
| 26 |
3.31 |
84.07 |
1/2 |
12 |
3/4 |
16 |
3/4 |
16 |
| 27 |
3.43 |
87.12 |
1/2 |
12 |
- |
16 |
- |
16 |
| 28 |
3.55 |
90.17 |
1/2 |
12 |
- |
16 |
- |
16 |
| 30 |
3.79 |
96.27 |
1/2 |
12 |
3/4 |
16 |
3/4 |
16 |
| 32 |
4.03 |
102.36 |
1/2 |
14 |
- |
16 |
- |
16 |
| 35 |
4.39 |
111.51 |
5/8 |
14 |
- |
16 |
- |
16 |
| 36 |
4.51 |
114.55 |
5/8 |
16 |
3/4 |
16 |
3/4 |
16 |
| 40 |
4.99 |
126.75 |
5/8 |
16 |
- |
16 |
- |
|
| 42 |
5.23 |
132.84 |
5/8 |
16 |
3/4 |
20 |
3/4 |
|
| 45 |
5.59 |
141.99 |
5/8 |
16 |
- |
20 |
- |
20 |
| 48 |
5.95 |
151.13 |
5/8 |
16 |
3/4 |
20 |
3/4 |
|
| 52 |
6.43 |
163.32 |
- |
20 |
3/4 |
20 |
3/4 |
20 |
| 54 |
6.66 |
169.16 |
5/8 |
20 |
- |
20 |
- |
|
| 60 |
7.38 |
187.45 |
3/4 |
20 |
3/4 |
20 |
3/4 |
25 |
| 68 |
8.34 |
211.84 |
- |
20 |
3/4 |
20 |
3/4 |
|
| 70 |
8.58 |
217.93 |
3/4 |
20 |
- |
20 |
- |
|
| 72 |
8.81 |
223.77 |
3/4 |
20 |
3/4 |
20 |
3/4 |
|
| 76 |
9.29 |
235.97 |
- |
20 |
3/4 |
20 |
3/4 |
|
| 80 |
9.77 |
248.16 |
3/4 |
20 |
- |
20 |
- |
|
| 84 |
10.25 |
260.35 |
3/4 |
20 |
3/4 |
20 |
3/4 |
|
| 95 |
11.56 |
293.62 |
- |
25 |
1 |
25 |
1 |
25 |
| 96 |
11.68 |
296.67 |
3/4 |
|
1 |
|
1 |
|
| 102 |
12.40 |
314.96 |
- |
|
1 |
|
1 |
|
| 112 |
13.59 |
345.19 |
3/4 |
|
- |
|
- |
|
|
